Product Details
Ceiling：Polymer metal plate, LED lights
Car door：Polymer metal plate
Side wall：Polymer metal plate, mirroretched stainless steel
Back wall：Polymer metal plate, mirroretched stainless steel
Handrail：Stainless steel round handrail
Floor：PVC
Passenger Elevator parameters
| 小机房客梯 MR Passenger Elevator |
无机房客梯 MRL Passenger Elevator |
|||
| 小值Minimum value | 大值Maximum value | 小值Minimum value | 大值Maximum value | |
| 速度(m/s) Speed |
1.0 | 3.0 | 1.0 | 2.0 |
| 载重(kg) Load capacity |
450 | 2000 | 450 | 1600 |
| 底坑深度(mm) Depth of the pit bottom |
1200 | 2000 | 1550 | 1750 |
| 顶层高度(mm) Top floor height |
4200 | 5000 | 4200 | 4750 |
| 开门尺寸(mm) Door opening dimensions |
800*2100 | 1200*2000 | 800*2100 | 1100*2100 |
| 井道尺寸(mm) Carriage shaft dimensions |
1800*1800 | 2900*2500 | 2000*1800 | 2800*2400 |
| 轿厢尺寸(mm) Carriage dimensions |
1200*1050*2500 | 1900*2100*2500 | 1100*1150*2500 | 1700*2000*2500 |
