Equal transport, harmonious space
Human-centered installation height is convenient for the disabled to freely enter into/ exit from the elevator. Embedded installation saves the car space. It avoids anycollision injury. High-recognition braille buttons are convenient to use by theamblyope. Furthermore, optional time-delay opening / closing function can prolongthe opening condition when passengers enter into / exit from the elevators.
Anion car technology
It firstly uses "natural oxygen bar" car technology. Air anion is like vitamin in food.It is vital to human life activities. It adds oxygen anion in the air, improves air qualityin the car. It is more beneficial for patients to travel the elevator.
医用梯
Hospital Elevator |
| |
小值Minimum value |
大值Large value |
速度(m/s)
Speed |
1 |
1.75 |
载重(kg)
Load capacity |
1600 |
底坑深度(mm)
Depth of the pit bottom |
1200 |
1350 |
顶层高度(mm)
Top floor height |
4300 |
4500 |
开门尺寸(mm)
Door opening dimensions |
1100*2100 |
1200*2100 |
井道尺寸(mm)
Carriage shaft dimensions |
2600*2900 |
轿厢尺寸(mm)
Carriage dimensions |
1400*2400*2500 |
